8W Emergency LED Driver, 25-56V DC Output

Description

GLT DIVA DIVA-CM08D-056A 7W Emergency Driver — 25-56V DC

The GLT DIVA DIVA-CM08D-056A is a 7-watt Emergency Driver designed to deliver reliable 25-56V DC output for emergency lighting applications. This unit operates within a wide input voltage range of 120-277V, making it versatile for various installations. It features a constant power performance, ensuring consistent illumination throughout its 90-minute emergency runtime. The driver is housed in a durable metal enclosure and is IP65 rated, making it suitable for use in damp locations. The DIVA-CM08D-056A is non-dimmable, simplifying its integration into existing systems.

Key Features

• Output Power: Delivers a consistent 8W output, maintaining illumination during emergencies.
• Output Voltage: Provides a 25-56V DC output, suitable for various LED configurations.
• Dimming: Non-dimmable design for straightforward emergency operation.
• Minimum Load: Not applicable, ensuring compatibility with a wide range of fixtures.
• Dimensions: Compact design with dimensions of 9.45 in. L x 1.79 in. W x 1.20 in. H.
• Enclosure Type: Durable metal enclosure with IP65 rating for protection against dust and water.
• IP Rating: IP65 rated, suitable for damp locations.
• Class 2: Output is Class 2 compliant, ensuring safe operation.
• Certifications: Meets NEC, IBC, and Life Safety Code requirements, RoHS compliant.

Physical Design & Installation

The emergency driver is encased in a robust metal enclosure, designed to withstand challenging environments. It includes an integrated test switch and charge indicator light for easy monitoring.

Dimming & Controls

This unit is non-dimmable, simplifying its use in emergency applications. It automatically switches to emergency mode upon AC power failure, ensuring uninterrupted lighting.

Performance & Build

Features short circuit, over-voltage, and thermal protection. It is Class 2 compliant and IP65 rated, providing reliable performance in damp locations.

Typical Applications

• Commercial buildings
• Industrial facilities
• Public spaces
• Emergency lighting systems
