AFX Elena ELNU Series LED Under Cabinet Light – Pivoting Bar, 5-CCT Selectable

Description

Overview

The AFX Lighting Elena ELNU Series delivers professional-grade undercabinet illumination in an ultra-low-profile design. These LED task lights feature a pivoting light bar for adjustable beam angles, making them ideal for kitchens, study areas, and displays where direct light is needed most. With only 1″ depth and extruded aluminum construction, the Elena series mounts discreetly under cabinets while providing linkable power up to 200 watts across multiple fixtures.

Available in five different lengths (10″, 14″, 22″, 32″, 40″) and both black or white finishes, the Elena series offers flexible configuration options to handle most application requirements. The integrated 5-CCT color changing switch allows you to select from 2700K, 3000K, 3500K, 4000K, or 5000K color temperatures to match your space perfectly.

Features

• Pivoting Light Bar: Adjustable beam angle directs light exactly where needed
• 5-CCT Color Changing Switch: User-selectable color temperatures – 2700K, 3000K, 3500K, 4000K & 5000K
• USB Charging Ports: Integrated USB-A and USB-C charging ports (on 14″, 22″, 32″, 40″ models only)
• Linkable Design: Connect up to 200 watts of fixtures together
• Dimmable: Compatible with most standard 2-wire (Triac) wall dimmers or electronic low voltage dimmer switch (sold separately)
• Flexible Installation: Direct wire option through multiple knockouts or plug-in with power cord (sold separately)
• BX/NM Cable Connector: Included for hardwire installations
• Direct Connector: Included for seamless fixture linking
• Multiple Sizes Available: Choose from 10″, 14″, 22″, 32″, or 40″ lengths
• Two Finish Options: Black or white painted metal to match your décor

Specifications

• Series: Elena Task Lighting ELNU
• Wattage Range: 5W to 20W (depending on size)
• Lumen Output: 285 to 1341 lumens (depending on size)
• Color Temperature: Selectable 2700K / 3000K / 3500K / 4000K / 5000K CCT
• CRI: 90 CRI (high color rendering)
• Lifespan: Rated to 50,000 hours
• Input: 120V 60 Hz
• Housing: Extruded aluminum construction
• Diffuser: White polycarbonate
• Certification: cETLus listed for indoor damp locations, Title 24/JA8 Compliant
• Warranty: 5 years from date of purchase (free from defects in materials and workmanship)

Size-Specific Specifications

• 10″ (ELNU10BK/WH): 5W, 285 lumens
• 14″ (ELNU14BK/WH): 8W, 508 lumens, includes USB ports
• 22″ (ELNU22BK/WH): 12W, 805 lumens, includes USB ports
• 32″ (ELNU32BK/WH): 16W, 1094 lumens, includes USB ports
• 40″ (ELNU40BK/WH): 20W, 1341 lumens, includes USB ports

Applications

The Elena ELNU Series is ideal for:

• Kitchen undercabinet task lighting
• Study area and desk illumination
• Display case and shelf lighting
• Workbench and workshop task lighting
• Closet and pantry illumination
• Retail display and merchandising
• Any application requiring adjustable, low-profile linear lighting

Available Accessories (sold separately): Interconnect cords in 12″, 24″, 36″, 48″, and 72″ lengths (white or black), 60″ cord & plug sets (white or black), hardwire boxes (white or black), clear cord clips with screws, and occupancy sensors.
