Magnitude Lighting M-Series 150W LED Driver — 24V DC
M150L24DC-AR is a 150W Constant Voltage LED Driver with 120VAC input and 24V DC output for 24V LED lighting systems. It is phase dimmable using a leading (forward) edge MLV TRIAC dimmer only and is built in a coated metal housing with an Integrated Junction Box and multiple 7/8 in. knockouts. This model includes primary and secondary auto-reset circuit breakers for load and driver protection.
Key Features
- Power: 150W max
- Input Voltage: 120VAC ± 5%, 50/60Hz
- Output Voltage: 24VDC
- Driver Type: Constant Voltage (magnetic)
- Dimming: Phase dimmable with leading (forward) edge MLV TRIAC dimmer only
- Minimum Dimming Level: 1%
- Dimensions: 9.80 in. L x 3.00 in. W x 2.74 in. H
- Enclosure Type: Integrated Junction Box with multiple 7/8 in. knockouts
- Environmental: Dry & Damp
- Listings: ETL Listed; conforms to UL STD 2108; C22.2 No. 223
Physical Design & Installation
Housed in a coated metal enclosure designed for contractor-friendly mounting and wiring. The Integrated Junction Box includes multiple 7/8 in. knockouts to simplify conduit entry and field connections.
Dimming & Controls
Phase dimming is supported with a leading (forward) edge MLV TRIAC dimmer only. Dimming performance is specified down to 1% minimum dimming level. Use a compatible MLV TRIAC control and follow standard phase-dimming wiring practices for 120VAC input and 24VDC output systems.
Performance & Build
Designed with primary and secondary auto-reset circuit breakers to help protect both the driver and the connected LED load. Rated for Dry & Damp environments and ETL Listed to UL STD 2108 with C22.2 No. 223 conformity.
Typical Applications
- 24V LED tape and accent lighting
- Linear and undercabinet lighting systems
- Residential and commercial retrofits using MLV TRIAC dimmers
- Dry or damp indoor areas
