RAB EM Emergency Unit, 90-Min Backup, 120-277V, Wall Mount, White

Description

RAB Lighting EM Emergency Unit — 90-Minute Battery Backup, 120-277V Input

The RAB Lighting EM is a robust emergency unit designed for reliable performance in critical situations. Featuring a 90-minute battery backup and operating on 120-277V, this unit ensures safety compliance in various environments. Constructed from durable thermoplastic, it is suitable for both dry and damp locations, making it a versatile choice for emergency lighting needs.

Key Features

• Battery Backup: Provides 90 minutes of emergency illumination with a nickel-cadmium battery.
• Voltage Range: Compatible with 120-277V input for flexible installation.
• Construction: Made from durable thermoplastic material for longevity and reliability.
• Mounting: Wall mount design with a maximum height of 8 feet for optimal coverage.
• Illumination: Two square heads provide 200 lumens of light output.
• Recharge Time: Requires 24 hours to fully recharge after use.
• Operating Temperature: Functions efficiently between 32°F and 104°F.
• Compliance: UL924 listed and Title 20 compliant for safety and energy efficiency.

Performance & Illumination

The unit features two square heads that deliver a total of 200 lumens, ensuring adequate lighting during emergencies. It is designed to provide clear visibility in critical situations.

Electrical & Battery

Operates on a 120-277V input with a nickel-cadmium battery that provides 90 minutes of backup power. The unit requires 24 hours to recharge fully and includes a manual test switch for functionality checks.

Physical & Installation Details

Constructed from white thermoplastic, the unit is lightweight and easy to install. It includes all necessary hardware for wall mounting and is designed for a maximum mounting height of 8 feet.

Compliance & Safety

UL924 listed and Title 20 compliant, the unit is suitable for use in dry and damp environments. It operates within a temperature range of 32°F to 104°F, ensuring reliability in various conditions.

What’s Included

• RAB Lighting EM Emergency Unit
• Wall Mounting Hardware
• Installation Instructions
