RAB RBAY17SHO/480 Field-Adjustable High Output Linear LED High Bay — 130W / 100W / 80W Selectable
The RAB RBAY17SHO/480 is a field-adjustable high output linear LED high bay delivering up to 20,965 lumens with selectable wattage options of 130W, 100W, and 80W and selectable CCT of 4000K / 5000K. The fixture operates on 480V with integrated 0–10V dimming to 10%. It is UL Listed for damp locations and is DLC Premium Listed for rebate eligibility. Designed for warehouses, distribution centers, industrial facilities, retail areas, and other high-ceiling commercial or industrial spaces requiring robust 480V illumination.
Key Features
- Selectable Wattage: 130W / 100W / 80W
- Selectable CCT: 4000K / 5000K
- Maximum Output: Up to 20,965 lumens
- Dimming: 0–10V dimming to 10%
- Environmental Rating: UL Listed for damp locations
- Certifications: UL Listed; DLC Premium Listed
- Rated Life: 100,000 hours (L70)
- Operating Temperature: -40°C to 50°C (-40°F – + 122°F)
Typical Applications
- Warehouses
- Distribution centers
- Industrial workshops
- Retail stockrooms
- Gymnasiums
- Manufacturing facilities
- High-bay commercial spaces
Performance & Light Output:
Delivered lumen output depends on selected wattage and CCT. The LED system is engineered for high efficacy performance with CRI typically in the mid-80s and a 100,000-hour L70 rated life.
Electrical & Controls:
Operates on 480V, 50/60 Hz with a constant current Class 1 driver. Integrated 0–10V dimming supports dim-to-10% control systems for energy management and flexible lighting control.
Construction & Durability:
Die-cast aluminum housing with polycarbonate lens. Rated for damp locations with rugged construction suitable for commercial and industrial environments. Mercury-free and RoHS-compliant components provide long life and environmental safety.
Installation & Mounting:
Includes V-hooks and chain for suspension mounting. Optional surface and pendant mounting kits are available separately to support varied installation needs.
Included
LED linear high bay fixture, V-hooks, and chain.
