RAB VXLED13DG LED Jelly Jar Vaporproof Ceiling Light 729 Lumens 13W 5000K 120–277V Natural Aluminum

Description

RAB VXLED13DG LED Jelly Jar Vaporproof Ceiling Light — IP65 Wet Rated Downlight

The RAB VXLED13DG is an LED jelly jar vaporproof ceiling light designed for wet location applications as a sealed downlight. It delivers approximately 729 lumens at 13W with a fixed 5000K color temperature and operates on a universal 120–277V driver. Engineered for industrial and commercial wet environments, it includes an all die-cast aluminum housing with shot-blasted guard and thermal shock-resistant frosted glass globe for durability and reliable performance.

Key Features

• Output: ~729 lumens
• Wattage: 13W
• CCT: 5000K fixed (cool)
• Voltage: 120–277V universal input
• Driver: Constant current, 100–277V, 50/60 Hz
• Wet Location: UL listed suitable for wet locations as a downlight
• Construction: Die-cast aluminum housing with silicone gaskets
• Guard & Globe: Shot-blasted protective guard and frosted glass globe
• Operating Range: -40°F (-40°C) to 104°F (40°C)
• Rated Life: 100,000 hours L70 (TM-21/LM-80)
• Surge Protection: 4 kV
• BUG Rating: B0 U3 G1
• TAA Compliant: Meets Trade Agreements Act requirements
• Warranty: 5-year limited warranty

Typical Applications

• Exterior ceilings
• Industrial corridors
• Stairwells
• Utility and maintenance areas
• Wet location indoor/outdoor spaces
• Service areas requiring sealed lighting

Performance & Light Output

Delivers approximately 729 lumens with an efficacy of ~48.3 lm/W. Color accuracy is ~65 CRI at 5000K, providing cool white illumination for general areas. Rated LED lifespan is 100,000 hours (L70) based on IES LM-80 and TM-21 testing. :contentReference[oaicite:0]{index=0}

Electrical & Controls

Operates on 120–277V, 50/60Hz constant current driver. Driver supplies consistent current across input range and includes 4 kV surge protection. Dimming is not listed for this model. :contentReference[oaicite:1]{index=1}

Construction & Durability

Rugged die-cast aluminum housing and driver housing with high-temperature silicone gaskets provide moisture sealing and vaporproof performance. Shot-blasted protective guard and thermal shock-resistant frosted glass globe protect the LED and diffuser. Rated for wet locations with cold weather starting to -40°F (-40°C) and ambient operation to 104°F (40°C). :contentReference[oaicite:2]{index=2}

Installation & Mounting

Ceiling-mount vaporproof design with three 1/2? NPS conduit entry points for sealed conduit entry. Suitable for surface ceiling installations in wet and industrial environments. :contentReference[oaicite:3]{index=3}

Included

• LED fixture
• Protective guard
• Frosted glass globe
