Sylvania Dual Selectable Square Canopy Light 4500 Lumens 30W Selectable CCT 120-347V White

Description

Sylvania Dual Selectable Square Canopy Light – 30W Configuration

The Sylvania SYLV-66409 is a versatile canopy light offering 4500 lumens at 30 watts with selectable color temperatures of 3000K, 4000K, and 5000K. Designed for both garage and canopy applications, it operates on 120-347V and is DLC 5.1 Premium listed, ensuring high energy efficiency and eligibility for utility rebates.

Key Features

• Dual Beam Optics: Seamlessly meets both garage and canopy lighting requirements without the need for lens swaps.
• Selectable Wattage: Offers flexibility with 15/20/30W settings for various lighting needs.
• Embedded Uplight: Reduces the ‘cave effect’ for a more welcoming environment.
• Controls Ready: Features a sensor receptacle for field-installable sensors, enhancing control options.
• Integrated Photocell: Automatically adjusts lighting based on ambient light levels.
• Dimmable: Supports 0-10V dimming for customizable light levels.
• Surge Protection: Equipped with 6kV surge protection for enhanced durability.
• High CRI: CRI greater than 80 for accurate color rendering.
• Long Lifespan: Rated for 100,000 hours (L70) at 25°C, ensuring longevity.
• Optional Emergency Backup: Available for added security during power outages.

Typical Applications

• Parking Garages
• Canopy Installations
• Commercial Garages
• Retail Storefronts
• Service Stations

Performance & Light Output

With a light output of 4500 lumens and efficacy up to 150 LPW, this fixture ensures bright and efficient illumination. It maintains a CRI greater than 80, providing excellent color rendering.

Electrical & Controls

Operating on 120-347V, the fixture supports 0-10V dimming and includes an integrated photocell. It features a power factor greater than 0.9 and a total harmonic distortion less than 20%.

Construction & Durability

The fixture is constructed with a robust housing and is IP65 rated for wet locations, ensuring reliable performance in various environments. It operates in temperatures ranging from -40°F to +122°F.

Installation & Mounting

Designed for surface or pendant mounting, the fixture includes necessary hardware for easy installation. Optional mounting plates are available for specific applications.

What’s Included

• Canopy Light Fixture
• Integrated Photocell
