WAC Lighting Cct Puck 2.75 in. Puck Light Kit, Brushed Nickel, Selectable CCT, 290 Lumens, 120V
Sale!

WAC Lighting Cct Puck 2.75 in. Puck Light Kit, Brushed Nickel, Selectable CCT, 290 Lumens, 120V

Original price was: $96.95.Current price is: $29.08.

Color:

SKU: 7296753926202 Category:

Description

WAC Lighting Cct Puck Light Kit — Brushed Nickel & Selectable CCT

The WAC Lighting HR-AC73-CS-BN in Brushed Nickel is a versatile puck light kit designed for undercabinet task lighting. This kit includes two double wire lights and one single wire light, each measuring 2.75 in. in diameter and 0.90 in. in height. Powered by 120V, it features an integrated LED light source with selectable color temperatures of 2700K, 3000K, and 3500K.

Key Features

  • Dimensions: Each puck measures 2.75 in. in diameter and 0.90 in. in height.
  • Voltage: Operates at 120 VAC, 50/60Hz.
  • Wattage: Consumes 4 watts per puck.
  • Lumens: Delivers 290 lumens per puck for bright task lighting.
  • Color Temperature: Selectable between 2700K, 3000K, and 3500K.
  • CRI: High color rendering index of 90 for accurate color representation.
  • Lifespan: Rated for 50,000 hours of use.
  • Mounting Options: Supports both recessed and surface mounting.
  • Dimming: Compatible with ELV dimmers for 100-10% dimming range.
  • Linkability: Connect up to 20 puck lights in a single run.
  • Construction: Die-cast aluminum housing with an acrylic diffuser.
  • Standards: ETL, cETL, and Title 24 JA8 compliant, suitable for damp locations.

Core Design & Profile

This puck light kit features a sleek, compact design with a die-cast aluminum housing and an acrylic diffuser, available in Brushed Nickel, Black, and White finishes. It is ETL and cETL listed for damp locations, ensuring reliable performance in various environments.

LED Illumination & Performance

Each puck light delivers 290 lumens with a power consumption of 4 watts, offering a high CRI of 90 for excellent color accuracy. The selectable CCT feature allows for customization between 2700K, 3000K, and 3500K, providing flexibility in lighting design.

Power, Wiring & Linkability

The HR-AC73-CS-BN operates on 120V and supports both direct wire and plug-in configurations. It includes a cord for easy installation and can link up to 20 puck lights per run, making it ideal for extended lighting applications.

Where This Fixture Works Best

  • Under kitchen cabinets
  • Display shelves
  • Workstations
  • Retail displays
  • Accent lighting

What’s Included

  • Two double wire puck lights
  • One single wire puck light
  • Installation cord
